我们的数采解决方案应用领域
Gantner Instruments提供跨多个行业的测量和控制采集解决方案
如今，在汽车驶上道路，直升飞机装载乘客，风力发电机产生能量，桥梁被投入使用或洗衣机开始处理家务之前，必须进行广泛的测试。 必须保证消费者期望并得到制造商承诺的诸如安全性、质量和使用寿命之类的特性。
我们为谁构建我们的数采产品和解决方案?
我们用于测试自动化的监控产品和解决方案可帮助研究机构、制造商和测试实验室负责任地完成这些任务。
我们的数采方案, 为您带来益处
Gantner Instruments提供标准化的数采产品和个性化测量解决方案以进行性能监控，使您能够更好地了解您的进程-从单个车辆零部件的生产到飞机的组装，从获得太阳能发电厂的特性到对建筑物进行长期监控。

Gantner Instruments公司成立于1982年，是多功能分布式采集和I / O系统的领先企业。在工业现场I / O总线领域，已经积累了超过25年的经验，并于1988年引进行业的第一个现场总线I / O模块（ISM01）。公司是电气、温度和机械量测量的佼佼者。我们的产品既有较高的性能和灵活性，又能保持简单的操作性，适用于各种复杂应用。

产品基于以太网，进行分布式采集，产品分为机架式和便携式。是工业和实验室测试的解决方案，应用领域：
       部件测试
       发动机测试
       过程监控
       长期监测…

主要产品：
Q.brixx gate

Basic system incl. Test Controller with Ethernet-TCP/IP interface, USB port for extendable data memory, PAC function, FTP functionality, incl. power suppy unit
Q.brixx A101

Measuring module with 2 multifunctional inputs for voltages, currents, resistance, Pt100, thermocouples, IEPE sensors, half and full bridges, measuring rate 100 kHz each channel, 2 digital in and outputs
Q.brixx A102

Measuring module with 1 multifunctional input for half and full bridge, IEPE sensor, voltage and current, measuring rate 100 kHz, 1 analog output and 2 digital in and outputs
Q.brixx A104

Measuring module with 8 galvanic isolated inputs for voltages and thermocouples, measuring rate 100 Hz each channel
Q.brixx A104 TCK

like Q.brixx A104 but with thermocouple connection over Mini TCK, other over quoting
Q.brixx A106

Measuring module with 2 inputs for strain gauge and inductive bridges, LVDT and RVDT, DC and carrier frequency excitation, measuring rate 10 kHz each channel, 1 analog output, 1 digital in and output each channel
Q.brixx A107

Measuring module with 4 multifunctional analog inputs for voltages, currents, resistance, Pt100, thermocouples and full bridges, measuring rate 10 kHz each channel
Q.brixx A108

Measuring module with 8 galvanic isolated inputs for voltage, measuring rate 10 kHz each channel, 2 digital in and outputs
Q.brixx A109

Analog module with 4 outputs, voltage or current selectable, up to 100 kHz, 4 digital in and 4 digital outputs for frequencies, counters, incremental sensors, PWM signals, duration or status signals
Q.brixx A123
      Measuringmodule with 4 galvanic isolated inputs for voltages, ranges 100 mV, 1 V, 10 V, measuring rate 10 kHz each channel, isolation voltage 1200 VDC permanent
Q.brixx A124

Measuringmodulewith 4 galvanic isolated inputs for thermocouples, measuring rate 10 kHz each channel, isolated voltage 1200 VDC permanent
Q.brixx A128

Measuringmodulewith 4 galvanic isolated inputs for voltages 40 V up to 1200 V, measuring rate up to 100 kHz each channel by using 2 channels, 50 kHz each channel by using 4 channels
Q.brixx A129

Measuring module with 4 galvanic isolated inputs for current measurement with external shunt, voltage input range 1 VDC, measuring rate up to 100 kHz each channel by using 2 channels, 50 kHz each channel by using 4 channels
Q.brixx D101

Digital multifunctional module with 8 digital inputs and 8 digital outputs for frequencies, counters, incremental sensors, PWM signals, duration or status signals

Q.raxx slimline, 19" System 1U
Q.raxx A101-8 slimline RS
19" measuring system with 8 analog multifunctional inputs for voltages, currents, resistance, Pt100, thermocouples, IEPE sensors, half and full bridges, measuring rate 100 kHz each channel
Q.raxx A101-8 slimline EC
like Q.raxx A101-8 slimline RS but with embedded Test Controller (Ethernet, EtherCAT, signal conditioning and PAC functionality)
